VISSONIC Wireless Conference 5G WiFi Wireless Digital Voting + Interpretation
Control &Indicators
Each unit with two-color LED indicator on microphone, red for speaking, green means need acceptance from chairman to speak
128x32 OLED display with volume bar, clock, time span of microphone activating, MIC ON/OFF etc and other information.
Indicator for Volume adjustment
5 voting keys with indicators, While no launching voting, no.2 and no.3 button is also work as channel selecting buttons, no.4 and no.5 work as volume buttons.
Indicator for MIC ON/OFF
Chairman unit with priority button and consent button for the delegates
Power ON/OFF button is hiding on the left side
Technical Parameters
Features
- Stylish, low profile design with touchable interface
- Wireless communication, setting up all system in few minutes to be ready for using, and put them away in short time as well
- 5 buttons for voting and ranking.
- Detachable battery pack is easy to replace and charge, working time is 22 hours, 30 hours for standby
- Built-in DC connector for power supply without battery
- Internal high fidelity loudspeaker
- built-in up 3 channels interpretation (optional on another model)
- Head-set interface in both sides with volume adjust
- Line-in interface which allows microphone or other line-in device like cell phone, laptop to pass audio through to perform teleconference
- Full-digital signal transmission and processing, completely avoid the RF interference from cell phone or similar devices.
- Support pluggable microphone and different length of microphone with strong audio collecting ability.
- Time and date display on the OLED screen
- Timer on display to set certain time for each delegate to speak, will remind user or close the MIC automatically
- All units can be configured as Chairman or Delegate unit through software settings based on model WVC-T.
- Compliance with IEC 60914,GBT 15381-94
- Standard Wi-Fi technology is compatible with other Wi-Fi networks, support 5GHz on all channels.
- All-digital transmission and processing technology in uncompressed audio, professional microphone to achieve perfect sound quality at 20Hz ~ 20KHz;
- 128 bits digital encryption technology, with WAP2 secure connection, MAC address filtering, SSID-hiding to prevent wiretapping and unauthorized access from delegate unit
- 8 units of delegates can open at the same time
- Support more AP working together to increasing the Wi-Fi coverage range for wireless MIC units working in a large conference room or multi-rooms
- With our HD camera and video matrix switcher, using RS485 or RS232 protocol to send the PELCO/VISCA protocol to realize camera auto-tracking function
- Precise directional microphone head with anti-wind microphone foam cover, with two-color LED indicator.
- 5 voting buttons and 1 MIC ON/OFF button, Priority & Apply Answer button for chairman unit
- Built-in high fidelity speakers, it automatically mutes to prevent howling when press MIC ON
- Head-set interface in both sides with volume adjust
- Support AGC(Automatic Gain Control)/AFC(Adaptive Feedback Cancellation)/ANC(Active Noise Control )/Mix (Auto-Mix) technology
- Build-in functions for intercom
- Without using PC software, our conference controller still owns following settings:
- Limit on the number of speaking persons: By Setting the number of active units at the same time(Number is 1/2/4/6/ units)
- Discussion modes:
- Voting function: Approve/Abstain/Object
- Chairman unit has priority to close all other units or mute them temporarily
- Chairman unit can answer the application for speaking from delegate
- Support more voting functions by the PC software
- The unit showing real time on the screen, and count-down timer for speaking person.
- Detachable battery pack is easy to replace and charge,power-saving technology to enable 20 hours continuous use and 48 hours for standby
Control &Indicators
Each unit with two-color LED indicator on microphone, red for speaking, green means need acceptance from chairman to speak
128x32 OLED display with volume bar, clock, time span of microphone activating, MIC ON/OFF etc and other information.
Indicator for Volume adjustment
5 voting keys with indicators, While no launching voting, no.2 and no.3 button is also work as channel selecting buttons, no.4 and no.5 work as volume buttons.
Indicator for MIC ON/OFF
Chairman unit with priority button and consent button for the delegates
Power ON/OFF button is hiding on the left side
Technical Parameters
Button | Touchable interface, no physical buttons |
Sound Pickup | heart type capacitance |
Display | OLED display 128 × 32 |
Sensitivity | -46 dBV / Pa |
Maximum power consumption | 2.0W |
Directivity | 0 ° / 180 °> 20 dB (1 kHz) |
Headphone load | 16Ω |
Headphone volume | 10mW |
Headphone jack | 3.5mm stereo |
Input impedance | 2kΩ |
SNR | 70dB |
Frequency response | 20 ~ 20000Hz |
Equivalent noise | 20dBA (SPL) |
Main material | ABS |
Operating temperature | 0 ºC to + 55 ºC |
Color | Black |
The maximum sound pressure | 125dB (THD <3%) |
Weight | 1.1kg (with microphone) |
Dimension | 185 × 130 × 50mm (width ×depth ×height) (without microphone) |
Connection | CAT5 / CAT6 cable + snap |
